Brand Name : TINKO/OEM
Model Number : KTQG - 24100
Certification : CE/ROHS/MSDS/UN38.3
Place of Origin : China
MOQ : 1PC
Price : Negotiable
Supply Ability : 100pcs/day
Packaging Details : 1pc/parer carton
Battery Type : Lifepo4
Voltage : 24V
Capacity : 100AH
Weight : 24kg
Size : 635*355*348mm
Model : KTQG-24100
Package : Paper Carton
Original : Dongguan, China
Deep Cycle 24V 100Ah LiFePO4 Battery with Long Lifetime up to 6000 Cycles
Product Description
TINKO 24V 100Ah LiFePO4 battery pack also made by A grade lifepo4 battery cell which is more stable and have a higher energy density. They are widely used in many areas such as RV, Solar system, Household Battery back up, Marine, Off-Grid and Electric Scooter, Electric Handicap and so on. Each battery has intelligent BMS to ensure safe and efficient operation.
Product Parameters
NO |
Projects |
Specification |
Remark |
电池单体参数Cell unit parameter | |||
1 |
Battery types and materials | LiFePO4 | |
2 |
Rated voltage/capacity | 3.2V / 100Ah | |
3 |
Single battery voltage range | 2.5V~3.65V | |
4 |
Single battery weight | 1.92Kg | |
5 |
The battery internal resistance | ≤ 0.5mΩ | |
6 |
Battery size | 50*160*116mm | |
Battery parameter | |||
1 |
Rated voltage | 25.6V | |
2 |
Rated capacity | 100Ah | |
3 |
Battery pack voltage range | 20~29.2V | |
4 |
Total Power | 2.56KWh | |
5 |
Combination | 8S1P | |
6 |
Insulation resistance test value | ≥1.2MΩ | |
7 |
Operating temperature | Charging 0 ~ 55℃; Discharging -20 ~ 60℃ | |
8 |
Standard charging current | 0.2C | |
9 |
Quick charging current | 0.5C | |
10 |
Standard discharge current | 0.5C | |
11 |
Maximum continuous discharge current | 1C | |
12 |
Gross weight | Around 22KG | |
13 |
Ambient relative humidity | 20-85%RH | |
14 |
Battery size | 522*240*221mm |
![]() |
6000 cycles 24V 100AH Battery For Solor Energy Storage System Images |
